s8102bq_1
Figure 33
Aaching Front Flange 19-Inch, 2-Post Rack Bracket
Step 5
Use the rear ange on each bracket to aach the brackets to the rear of the rack at the required posion, as
shown in the following gure.
Note: Do not completely ghten the bolts, the bolts are completely ghtened later in the procedure.
(2) Screws on
this Side of Rail
s8102br_1
Figure 34
Aaching Rear Flange 19-Inch, 2-Post Rack Bracket
