Note: Each bracket is mounted to the rack using four bolts, two in the front and two in the rear.
Step 9
Tighten the ange nuts on both the le and right brackets, as shown in the following gure.
Note: Do not use excessive force to ghten the nuts.
Nuts
(2) Nuts on
this Side of Rail
s8102by_1
Figure 43
Tightening Flange Nuts 23-Inch, 2-Post Rack Bracket
The following gure shows the installed 23-inch, 2-post rack brackets.
