Fujitsu 1FINITY L100 User Manual

Flange Screws
Rear Flange
Front Flange
Left Bracket
Right Bracket
s8104am_1
Figure 53
Loosening Flange Screws 23-Inch, 4-Post Rack Bracket
Step 3
Adjust the width between the front ange and rear ange (on both brackets) to the width of the rack.
Step 4
Use the front ange on each bracket to aach the brackets to the front of the rack at the required posion, as
shown in the following gure.
Note: Do not completely ghten the bolts, the bolts are completely ghtened later in the procedure.
Equipment Installation
Install 23-Inch, 4-Post Rack Rail Kit
126
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
