Figure 54
Aaching Front Flange 23-Inch, 4-Post Rack Bracket
Step 5
Use the rear ange on each bracket to aach the brackets to the rear of the rack at the required posion, as
shown in the following gure.
Note: Do not completely ghten the bolts, the bolts are completely ghtened later in the procedure.
Equipment Installation
Install 23-Inch, 4-Post Rack Rail Kit
