Warning: To prevent damage to the PIU, never force a PIU into posion.
Note: Make sure that the locking lever locks in place. If the locking lever is hard to lock into place, press the
release buon in the middle of the locking lever.
FNC000044_Rev_01
Figure 82
Locking PIU in Place
Step 7
Record the installaon in accordance with local record-keeping procedures.
✓ This task is complete.
Addional Instrucons:
Perform the same procedure to install all required PIUs.
Equipment Installation
Install Plug-In Unit
