Fiber Management Arm
Do not lift here. Do not lift here.
Lift here. Lift here.
s8102bb_1
Figure 123
Removing Blade from Packing Container
Step 19
Inspect the equipment to ensure that it is free of any defects, damage, or other debris. If the equipment is
damaged, follow local pracces/procedures for repair or replacement of the damaged unit, as applicable.
Note: Use the checklist accompanying each shipment (if applicable) to verify that all items are present with the
shipment.
Step 20
Record the serial number and issue number of the equipment in accordance with local record-keeping
procedures, if necessary.
Step 21
Insert the hooks on the power terminal adapter into the holes on the rear of the blade.
System Maintenance
Equipment Replacement
377
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
