Fiber Restraint
Gate
Open
Closed
PIU Slots
Set Screw
FNC000054_Rev_01
Figure 135
Unlatching Fiber Restraint Gate
Step 7
Aer opening the ber restraint gates, carefully loosen the set screws on the le-hand and right-hand sides of
the blade, using a Phillips head screwdriver, to detach from the rack.
Note: The set screws are accessible aer opening the ber restraint gates on the le- and right-hand sides of
the blade.
Step 8
Close both ber restraint gates aer loosening the set screws and disengaging the blade from the rack.
System Maintenance
Equipment Replacement
387
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
