Set Screw
Fiber Restraint
Gate
Open
Closed
PIU Slots
s8102ay_3
Figure 136
Latching Fiber Restraint Gate
Step 9
At the front of the blade, use the ber management arms to slowly pull the blade out of the rack to the locked
posion.
At the locked posion, the locks on both sides of the blade stop the blade at approximately halfway out.
Aenon: Do not touch the opcal bers in adjoining slots. Make sure bers from other blades do
not obstruct the blade being removed.
System Maintenance
Equipment Replacement
388
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
