Step 15
On a at ESD-safe surface carefully loosen the aachment screws. Loosen the screws unl they are fully
disengaged from the blade.
Figure 142
Aachment Screws
Step 16
Conrm the screws have been fully disengaged from the blade.
Cauon
: The blade and power terminal adapter may be damaged if the screws are not fully disengaged
from the blade.
Step 17
Slightly lt the power terminal adapter forward away from the blade.
Figure 143
Tilng Power Terminal Adapter
