s8102cv_1
Figure 159
Locked Posion
Warning: The blade is heavy; always use two hands and be prepared to support the enre weight of the
blade aer releasing the blade from the locked posion.
Step 8
Find the locking tabs on each side of the blade.
Step 9
With the blade at the locked posion, place one hand on each side of the blade.
Step 10
Press both locking tabs UP and slowly pull the blade to release. Connue pulling blade unl fully removed from
the Housing.
System Maintenance
Equipment Replacement
405
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
