Note: The set screws are accessible aer opening the ber restraint gates on the le- and right-hand sides of
the blade.
Step 6
Close both ber restraint gates aer loosening the set screws and disengaging the blade from the Housing.
Step 7
At the front of the blade, use the ber management arms to slowly pull the blade out of the Housing to the
locked posion.
At the locked posion, the locks on both sides of the blade stop the blade at approximately halfway out.
Aenon: Do not touch the opcal bers in adjoining slots. Make sure bers from other blades do
not obstruct the blade being removed.
Fiber Management Arms
s8102ct_1
Figure 158
Pulling Blade from Housing
System Maintenance
Equipment Replacement
404
Release 19.1.1 · Issue 1.1, May 2021
