Step 16
Insert the blade into the appropriate slot of the 1FINITY Housing and slide it back unl it locks in place.
Note: Fujitsu recommends installing the blade without the PIUs installed.
Fiber Management Arm
Do not lift here.
Do not lift here.
Lift here.
Lift here.
s8102ba_1
Figure 163
Proper Method to Li Blade
System Maintenance
Equipment Replacement
