Fiber Management Arms
s8102ct_1
Figure 183
Pulling Blade from Housing
s8102cv_1
Figure 184
Locked Posion
Step 5
Warning:
The blade is heavy; always use two hands and be prepared to support the enre weight of the
blade aer releasing the blade from the locked posion.
Equipment Removal
Remove Blade from Housing
445
