Remove the blade by performing the following substeps:
a) Find the locking tabs on each side of the blade.
b) With the blade at the locked posion, place one hand on each side of the blade.
c) Press both locking tabs UP and slowly pull the blade to release. Connue pulling blade unl fully removed
from the Housing.
Unlock
s8102cw_2
Figure 185
Unlocking Blade from Housing
Equipment Removal
Remove Blade from Housing
