Value Units / Interpretation RFID Configuration Definition / Function
ALn where n:
E = Enable
D = Disable
Allows locking the AFI after writing (HF only).
Bn where n:
D = Disable
Disables padding or truncating of data (EPC only).
Nulls are represented as “00”.
For Hex EPC data a 96-bit tag size is 24 characters and 64-bit is
16.
For ASCII EPC data a 96-bit tag size is 12 characters and 64-bit
is 8.
1 = Leading
If the data is less than the selected EPC tag data size, nulls will
be added to the front (left); or, if too much data is given, the data
will be cut.
2 = Trailing
If the data is less than the selected EPC tag data size, nulls will
be added to the back (right); or, if too much data is given, the
data will be cut.
DIhh where hh:
2-Chararacter
Hex ID
Sets the Data Storage Format Identifier (DSFID), HF only.
DLn where n:
E = Enable
D = Disable
Allows locking the DSFID after writing (HF only).
En where n:
E = Enable
D = Disable
Allows erasures of the tag on error (HF only).
Lhh where hh:
2-Chararacter
Hex ID
Sets the Lock Code (Alien UHF only).
Mn where n:
D = Disable Disables the RFID module. (“N” is also a valid disabler.)
H = HF Enables the RFID module for HF (Securakey).
U = UHF Enables the RFID module for UHF Class 1 (Alien).
M = UHF Enables the RFID module for UHF Multiprotocol.
Nn where n:
64 = 64-bit
96 = 96-bit
Sets the UHF tag data size (Multiprotocol UHF only).
