Pin
Number
Signal
Name
Signal
Direction
[1]
Jumper Position Function / Description
9
Ribbon
Low
Output JMP 1
When inactive,
outputs will be
pulled up to a
voltage determined
by this jumper
setting, where:
Pins 1 – 2 =
+5VDC;
Pins 2 – 3 =
+24VDC; or,
None = A common
external voltage
(not to exceed
+30VDC) via
external pull-ups
(providing a 20K
ohm feedback path
through any two
outputs).
Programmable [1]. Signifies a
RIBBON LOW DIAMETER warning.
10
Service
Required
Evoked by occurrences listed under
“Fault Messages”[1]. Active LOW.
11
End Of
Print
Programmable [1]. Signifies the End
of Print (EOP) process.
12 Media Out
Evoked during an Out of Stock
condition. Active LOW.
13
Ribbon
Out
Evoked during an Out of Ribbon
condition. Active LOW.
14
Data
Ready
Evoked when a label is waiting to be
printed. Then after the printer
receives the Start of Print signal,
printing will begin. For
synchronization with the print cycle,
the End Of Print signal indicates
the completion of the print process.
Active LOW.
15
Option
Fault
Evoked during a Linear Scanner or
RFID fault condition. Active LOW.
[1] Signal directions are given relative to the printer.
[2] If active with no current print job, “WAITING FOR DATA” will be displayed.
Specifying a quantity of 9999 while keeping this signal “On” will cause non-stop label
printing, except in single label “Imaging Mode”, which will cause the printer to stop
between labels
260
DPLCommand Reference
