The BGP view is displayed.
4. Run:
ipv4-family vpn-instance vpn-instance-name
The BGP VPN instance view is displayed.
5. Run:
import-route static [ med value ] [ route-policy policy-name ]
The static route is imported to the routing table of the BGP VPN instance.
l Configuring RIP between PE and CE
The configuration is performed on PEs. Configure RIPv1 and RIPv2 on CE. The
configuration procedure is not described here.
NOTE
For the configuration procedure of RIP, refer to RIP Configuration in the Quidway S9300 Terabit
Routing Switch Configuration Guide - IP Routing.
1. Run:
system-view
The system view is displayed.
2. Run:
rip process-id vpn-instance vpn-instance-name
The RIP instance is created between PE and CE and the RIP view is displayed.
A RIP process belongs to only one VPN instance. If a running RIP process is not
bound to a VPN instance, the RIP process belongs to a public network. In this case,
this process cannot be bound to a VPN instance.
3. Run:
network network-address
RIP is run in the network segment of the interface bound to the VPN instance.
4. Run:
import-route bgp [ cost value ] [ route-policy policy-name]
The BGP routes are imported.
After the import-route bgp command is run in the RIP view, the PE imports the
VPNv4 routes learned from the peer to RIP, and then advertises the routes to the
connected CE.
5. Run:
quit
The system view is displayed.
6. Run:
bgp as-number
The BGP view is displayed.
7. Run:
ipv4-family vpn-instance vpn-instance-name
The BGP VPN instance view is displayed.
8. Run:
import-route rip process-id [ med value ] [ route-policy policy-name ]
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN 3 BGP/MPLS IP VPN Configuration
Issue 03 (2009-08-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3-17
