NOTE
Compared with a common BGP view, the BGP VPN instance view does not support the
following commands:
l BGP confederation: confederation
l BGP Graceful Restart: graceful-restart
l Router ID of a BGP router: router-id
l Synchronization between BGP and IGP: synchronization
l BGP timer: timer
Do as follows on the PEs.
1. Run:
system-view
The system view is displayed.
2. Run:
bgp as-number
The BGP view is displayed.
3. Run:
peer peer-address as-number as-number
The PE is configured as the IBGP peer.
4. Run:
import-route { direct | static | rip [ process-id ] | ospf process-id |
isis process-id } [ med value | route-policy policy-name ]
*
The routes of the local site are imported.
The CE advertises the address of the local network segment to the connected PE, and
then the PE advertises the address to the remote CE. The type of routes to be imported
in this step varies according to the networking.
l Configuring a static route between PE and CE
The configuration is performed on PEs. The configuration of static routes on CE is the same
as the configuration of common static routes, and is not described here.
NOTE
For detailed configuration of the static routes, refer to Static Route Configuration in the Quidway
S9300Terabit Routing Switch Configuration Guide - IP Routing.
1. Run:
system-view
The system view is displayed.
2. Run:
ip route-static vpn-instance vpn-instance-name dest-ip-address { mask |
mask-length } { interface-type interface-number | vpn-instance vpn-
destination-name nexthop-address | nexthop-address [ public ] }
[ preference preference ] [ tag tag ] [ descriptiontext ]
The static route is configured for the specified VPN instance.
3. Run:
bgp as-number
3 BGP/MPLS IP VPN Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN
3-16 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2009-08-20)
