[Hub-PE-Vlanif20] mpls ldp
[Hub-PE-Vlanif20] quit
After the configuration, LDP peer relation can be set up between the Hub-PE and the Spoke-
PEs. Run the display mpls ldp session command on each S9300, and you can see that the session
status is Operational.
The configuration procedure of the Spoke-PE is similar to the configuration procedure of the
Hub-PE and is not mentioned here.
Step 3 Configure VPN instances on each PE and connect the CEs to the PEs.
NOTE
The VPN targets of the two VPNs on the Hub-PE are advertised by the two Spoke-PE, and the advertised
VPN target is different from the received VPN target. The import VPN target on the Spoke-PE is the export
VPN target on the Hub-PE.
# Configure Spoke-PE1.
<Spoke-PE1> system-view
[Spoke-PE1] ip vpn-instance vpna
[Spoke-PE1-vpn-instance-vpna] route-distinguisher 100:1
[Spoke-PE1-vpn-instance-vpna] vpn-target 100:1 export-extcommunity
[Spoke-PE1-vpn-instance-vpna] vpn-target 200:1 import-extcommunity
[Spoke-PE1-vpn-instance-vpna] quit
[Spoke-PE1] interface vlanif 50
[Spoke-PE1-Vlanif50] ip binding vpn-instance vpna
[Spoke-PE1-Vlanif50] ip address 100.1.1.2 24
[Spoke-PE1-Vlanif50] quit
# Configure Spoke-PE2.
<Spoke-PE2> system-view
[Spoke-PE2] ip vpn-instance vpna
[Spoke-PE2-vpn-instance-vpna] route-distinguisher 100:3
[Spoke-PE2-vpn-instance-vpna] vpn-target 100:1 export-extcommunity
[Spoke-PE2-vpn-instance-vpna] vpn-target 200:1 import-extcommunity
[Spoke-PE2-vpn-instance-vpna] quit
[Spoke-PE2] interface vlanif 60
[Spoke-PE2-Vlanif60] ip binding vpn-instance vpna
[Spoke-PE2-Vlanif60] ip address 120.1.1.2 24
[Spoke-PE2-Vlanif60] quit
# Configure the Hub-PE.
<Hub-PE> system-view
[Hub-PE] ip vpn-instance vpn_in
[Hub-PE-vpn-instance-vpn_in] route-distinguisher 100:21
[Hub-PE-vpn-instance-vpn_in] vpn-target 100:1 import-extcommunity
[Hub-PE-vpn-instance-vpn_in] quit
[Hub-PE] ip vpn-instance vpn_out
[Hub-PE-vpn-instance-vpn_out] route-distinguisher 100:22
[Hub-PE-vpn-instance-vpn_out] vpn-target 200:1 export-extcommunity
[Hub-PE-vpn-instance-vpn_out] quit
[Hub-PE] interface vlanif 30
[Hub-PE-Vlanif30] ip binding vpn-instance vpn_in
[Hub-PE-Vlanif30] ip address 110.1.1.2 24
[Hub-PE-Vlanif30] quit
[Hub-PE] interface vlanif 40
[Hub-PE-Vlanif40] ip binding vpn-instance vpn_out
[Hub-PE-Vlanif40] ip address 110.2.1.2 24
[Hub-PE-Vlanif40] quit
# Configure the IP addresses of the interfaces on the CEs. The configuration procedure is not
given here.
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN 3 BGP/MPLS IP VPN Configuration
Issue 03 (2009-08-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3-89
