[CE1] bgp 65410
[CE1-bgp] peer 10.1.1.2 as-number 100
[CE1-bgp] import-route direct
[CE1-bgp] quit
# Configure PE.
<PE> system-view
[PE] ip vpn-instance vpna
[PE-vpn-instance-vpna] route-distinguisher 100:2
[PE-vpn-instance-vpna] vpn-target 1:1
[PE-vpn-instance-vpna] quit
[PE] interface vlanif 40
[PE-Vlanif40] ip binding vpn-instance vpna
[PE-Vlanif40] ip address 10.2.1.2 24
[PE-Vlanif40] quit
[PE] bgp 100
[PE-bgp] ipv4-family vpn-instance vpna
[PE-bgp-vpna] peer 10.2.1.1 as-number 65420
[PE-bgp-vpna] import-route direct
[PE-bgp-vpna] quit
[PE-bgp] quit
# Configure CE2.
<Quidway> system-view
[Quidway] sysname CE2
[CE2] interface vlanif 40
[CE2-Vlanif40] ip address 10.2.1.1 24
[CE2-Vlanif40] quit
[CE2] bgp 65420
[CE2-bgp] peer 10.2.1.2 as-number 100
[CE2-bgp] import-route direct
[CE2-bgp] quit
After the configuration, run the display ip vpn-instance verbose command on the UPE and the
PE, and you can see the configuration of the VPN instances. By running the ping -vpn-
instance, you can see that the UPE and the PE can ping the connected CEs.
NOTE
If multiple interfaces on a PE are bound to the same VPN, you must specify the source address when you
run the ping -vpn-instance command to ping the CE connected to the peer PE. That is, specify -a source-
ip-address in the ping -vpn-instance vpn-instance-name -a source-ip-address destination-address
command. Otherwise, the ping operation may fail.
Step 4 Set up an MP-IBGP adjacency between UPE and SPE, and between PE and SPE.
# Configure the UPE.
<UPE> system-view
[UPE] bgp 100
[UPE-bgp] peer 2.2.2.9 as-number 100
[UPE-bgp] peer 2.2.2.9 connect-interface loopback 1
[UPE-bgp] ipv4-family vpnv4
[UPE-bgp-af-vpnv4] peer 2.2.2.9 enable
[UPE-bgp-af-vpnv4] quit
[UPE-bgp] quit
# Configure the SPE.
<SPE> system-view
[SPE] bgp 100
[SPE-bgp] peer 1.1.1.9 as-number 100
[SPE-bgp] peer 1.1.1.9 connect-interface loopback 1
[SPE-bgp] peer 3.3.3.9 as-number 100
[SPE-bgp] peer 3.3.3.9 connect-interface loopback 1
[SPE-bgp] ipv4-family vpnv4
[SPE-bgp-af-vpnv4] peer 1.1.1.9 enable
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN 3 BGP/MPLS IP VPN Configuration
Issue 03 (2009-08-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3-109
