Huawei Quidway S9300

<Quidway> system-view
[Quidway] sysname CE2
[CE2] vlan 20
[CE2-vlan20] quit
[CE2] interface GigabitEthernet1/0/0
[CE2-GigabitEthernet1/0/0]port link-type trunk
[CE2-GigabitEthernet1/0/0]port trunk allow-pass vlan 20
[CE2]quit
[CE2] interface vlanif 20
[CE2-Vlanif20] ip address 100.1.1.2 24
[CE2-Vlanif20] quit
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Configure PEs.
# Configure the LSR ID and enable MPLS and MPLS L2VPN.
<Quidway> system-view
[Quidway] sysname PE
[PE] interface loopback 1
[PE-LoopBack1] ip address 1.1.1.9 32
[PE-LoopBack1] quit
[PE] mpls lsr-id 1.1.1.9
[PE] mpls
[PE-mpls] quit
[PE] mpls l2vpn
[PE-l2vpn] quit
[PE] vlan batch 10 20
[PE] interface gigabitEthernet 1/0/0
[PE-GigabitEthernet1/0/0] port hybrid pvid vlan 10
[PE-GigabitEthernet1/0/0] port hybrid tagged vlan 10
[PE-GigabitEthernet1/0/0] quit
[PE] interface gigabitEthernet 2/0/0
[PE-GigabitEthernet2/0/0] port hybrid pvid vlan 20
[PE-GigabitEthernet2/0/0] port hybrid tagged vlan 20
[PE-GigabitEthernet2/0/0] quit
# Create a local connection between CE1 and CE2.
[PE] ccc ce1-ce2 interface Vlanif10 out-interface Vlanif20
Step 3 Verify the configuration.
After the configuration, display the CCC information on the PE. You can see that a local CCC
connection is set up and the status is Up.
<PE> display ccc
total ccc vc : 1
local ccc vc : 1, 1 up
remote ccc vc : 0, 0 up
name: ce1-ce2, type: local, state: up,
intf1: Vlanif10 (up), intf2: Vlanif20 (up)
Run the display l2vpn ccc-interface vc-type ccc command, and you can see that the VC type
is CCC and the status is Up.
<PE> display l2vpn ccc-interface vc-type all
Total ccc-interface of CCC : 2
up (2), down (0)
Interface Encap Type State VC Type
Vlanif10 vlan up ccc
Vlanif20 vlan up ccc
4 VLL Configuration
