Data Preparation
To complete the configuration, you need the following data:
l Out-label and in-label of the remote CCC connection
Pay attention to the mapping between the in-labels and out-labels on the PE and P. For the settings
of the out-label and the in-label, see Figure 4-5.
Procedure
Step 1 Configure the ID of the VLAN that each interface belongs to, as shown in Figure 4-5.
The configuration procedure is not mentioned here.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Assign the IP addresses to the VLANIF interfaces on the CEs.
# Configure CE1.
[CE1] interface vlanif 10
[CE1-Vlanif10] ip address 100.1.1.1 24
[CE1-Vlanif10] quit
# Configure CE2.
[CE2] interface vlanif 40
[CE2-Vlanif40] ip address 100.1.1.2 24
[CE2-Vlanif40] quit
Step 3 Assign an IP address to each VLANIF interface of the S9300s.
# Configure PE1.
<Quidway> system-view
[Quidway] sysname PE1
[PE1] interface loopback 1
[PE1-LoopBack1] ip address 1.1.1.9 32
[PE1-LoopBack1] quit
[PE1] interface vlanif 20
[PE1-Vlanif20] ip address 10.1.1.1 24
[PE1-Vlanif20] quit
# Configure the P.
<Quidway> system-view
[Quidway] sysname P
[P] interface loopback 1
[P-LoopBack1] ip address 2.2.2.9 32
[P-LoopBack1] quit
[P] interface vlanif 30
[P-Vlanif30] ip address 10.2.2.2 24
[P-Vlanif30] quit
[P] interface vlanif 20
[P-Vlanif20] ip address 10.1.1.2 24
[P-Vlanif20] quit
# Configure PE2.
<Quidway> system-view
[Quidway] sysname PE2
[PE2] interface loopback 1
[PE2-LoopBack1] ip address 3.3.3.9 32
[PE2-LoopBack1] quit
