LDP Session(s) in Public Network
------------------------------------------------------------------------------
Peer-ID Status LAM SsnRole SsnAge KA-Sent/Rcv
------------------------------------------------------------------------------
1.1.1.9:0 Operational DU Active 000:00:14 57/57
2.2.2.9:0 Operational DU Active 000:00:14 56/56
4.4.4.9:0 Operational DU Passive 000:00:05 22/22
5.5.5.9:0 Operational DU Passive 000:00:12 52/52
------------------------------------------------------------------------------
TOTAL: 4 session(s) Found.
LAM : Label Advertisement Mode SsnAge Unit : DDD:HH:MM
<S-PE> display mpls ldp peer
LDP Peer Information in Public network
------------------------------------------------------------------------------
Peer-ID Transport-Address Discovery-Source
------------------------------------------------------------------------------
1.1.1.9:0 1.1.1.9 Remote Peer : 1.1.1.9
2.2.2.9:0 2.2.2.9 Vlanif30
4.4.4.9:0 4.4.4.9 Vlanif40
5.5.5.9:0 5.5.5.9 Remote Peer : 5.5.5.9
------------------------------------------------------------------------------
TOTAL: 4 Peer(s) Found.
<S-PE> display mpls lsp
----------------------------------------------------------------------
LSP Information: LDP LSP
----------------------------------------------------------------------
FEC In/Out Label In/Out IF Vrf Name
3.3.3.9/32 3/NULL -/-
1.1.1.9/32 NULL/1024 -/Vlanif30
1.1.1.9/32 1024/1024 -/Vlanif30
2.2.2.9/32 NULL/3 -/Vlanif30
2.2.2.9/32 1025/3 -/Vlanif30
4.4.4.9/32 NULL/3 -/Vlanif40
4.4.4.9/32 1027/3 -/Vlanif40
5.5.5.9/32 NULL/1027 -/Vlanif40
5.5.5.9/32 1026/1027 -/Vlanif40
Step 5 Create and configure the PW template.
Create a PW template on each U-PE. Enable the CW and LSP ping function.
# Configure U-PE1.
[U-PE1] pw-template pwt
[U-PE1-pw-template-pwt] peer-address 3.3.3.9
[U-PE1-pw-template-pwt] control-word
[U-PE1-pw-template-pwt] vccv cc cw cv lsp-ping
[U-PE1-pw-template-pwt] quit
# Configure U-PE2.
[U-PE2] pw-template pwt
[U-PE2-pw-template-pwt] peer-address 3.3.3.9
[U-PE2-pw-template-pwt] control-word
[U-PE2-pw-template-pwt] vccv cc cw cv lsp-ping
[U-PE2-pw-template-pwt] quit
NOTE
You can configure a dynamic PW without using a PW template. If the PW template is not used, PW
connectivity cannot be verified and path information of the PW cannot be collected. That is, the ping vc
and tracert vc commands cannot be used.
Step 6 Create a VC connection.
Enable MPLS L2VPN on U-PE1, U-PE2, and S-PE.
