GigabitEthernet1/0/2 VLANIF 80 -
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure an IGP protocol on the backbone network.
2. Set up MPLS TE tunnels between PE1 and PE3, and LSPs between PE1 and PE2.
3. Set up MPLS LDP sessions between PE1 and PE2, and between PE1 and PE3.
4. Use PW templates to configure PWs on PEs. You need to use tunnel policies to configure
the master PW because the master PW uses the MPLS TE tunnel.
Data Preparation
To complete the configuration, you need the following data:
l Tunnel policy
l Bandwidth for MPLS TE tunnels
l Name of the remote peer of MPLS LDP
l VC IDs of the master PW and the backup PW
l Name of the PW template
Procedure
Step 1 Configure the VLAN that each interface belongs to.
The configuration procedure is not mentioned.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Configure an IGP protocol on the MPLS backbone network so that PEs and P can interwork.
# Configure PE1.
[PE1] interface loopback 1
[PE1-LoopBack1] ip address 1.1.1.1 32
[PE1-LoopBack1] quit
[PE1] interface vlanif 20
[PE1-Vlanif20] ip address 100.13.1.1 30
[PE1-Vlanif20] quit
[PE1] interface vlanif 40
[PE1-Vlanif40] ip address 100.12.1.1 30
[PE1-Vlanif40] quit
[PE1] ospf 1
[PE1-ospf-1] area 0
[PE1-ospf-1-area-0.0.0.0] network 1.1.1.1 0.0.0.0
[PE1-ospf-1-area-0.0.0.0] network 100.13.1.0 0.0.0.3
[PE1-ospf-1-area-0.0.0.0] network 100.12.1.0 0.0.0.3
[PE1-ospf-1-area-0.0.0.0] quit
[PE1-ospf-1] quit
# Configure the P.
5 PWE3 Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN
5-76 Huawei Proprietary and Confidential
