0x1003c cr lsp 2.2.2.2 2
0x1003d cr lsp 2.2.2.2 3
0x1001b lsp 2.2.2.2 0
0x1001c lsp -- 1
Step 4 Configure VPN instances on each PE and connect the CEs to the PEs.
# Configure PE1.
[PE1] ip vpn-instance VPNA
[PE1-vpn-instance-VPNA] route-distinguisher 100:1
[PE1-vpn-instance-VPNA] vpn-target 111:1 both
[PE1-vpn-instance-VPNA] quit
[PE1] ip vpn-instance VPNB
[PE1-vpn-instance-VPNB] route-distinguisher 100:2
[PE1-vpn-instance-VPNB] vpn-target 222:2 both
[PE1-vpn-instance-VPNB] quit
[PE1] interface vlanif 30
[PE1-Vlanif30] ip binding vpn-instance VPNA
[PE1-Vlanif30] ip address 10.1.1.2 30
[PE1-Vlanif30] quit
[PE1] interface vlanif 20
[PE1-Vlanif20] ip binding vpn-instance VPNB
[PE1-Vlanif20] ip address 10.2.1.2 30
[PE1-Vlanif20] quit
# Configure PE2.
[PE2] ip vpn-instance VPNA
[PE2-vpn-instance-VPNA] route-distinguisher 100:3
[PE2-vpn-instance-VPNA] vpn-target 111:1 both
[PE2-vpn-instance-VPNA] quit
[PE2] ip vpn-instance vpnb
[PE2-vpn-instance-VPNB] route-distinguisher 100:4
[PE2-vpn-instance-VPNB] vpn-target 222:2 both
[PE2-vpn-instance-VPNB] quit
[PE2] interface vlanif 50
[PE2-Vlanif50] ip binding vpn-instance VPNA
[PE2-Vlanif50] ip address 10.3.1.2 30
[PE2-Vlanif50] quit
[PE2] interface vlanif 40
[PE2-Vlanif40] ip binding vpn-instance VPNB
[PE2-Vlanif40] ip address 10.4.1.2 30
[PE2-Vlanif40] quit
# Configure the interface addresses of the VLAN where the CE interface resides and configure
the IP addresses of the VLANIF interfaces according to Figure 1-2. The configuration procedure
is not given.
# By running the display ip vpn-instance verbose command on the PEs, you can see the
configuration of the VPN instances. The PEs can ping the connected CEs successfully.
NOTE
If multiple interfaces on a PE are bound to the same VPN, you must specify the source address when you
run the ping command to ping the connected CE. That is, specify -a source-ip-address in the ping -a
source-ip-address -vpn-instance vpn-instance-name destination-address command; otherwise, the ping
operation may fail.
Step 5 Configure and apply a tunnel policy on the PE.
# Configure the tunnel policy for binding primary tunnel and apply the tunnel policy to VPNA.
# Configure PE1.
[PE1]tunnel-policy policy1
[PE1-tunnel-policy-policy1]tunnel binding destination 2.2.2.2 te tunnel1/0/2
[PE1-tunnel-policy-policy1] quit
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN 1 VPN Tunnel Management
Issue 03 (2009-08-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1-31
