Loopback1 - 2.2.2.9/32

PE3 GigabitEthernet1/0/1 VLANIF 3 -

GigabitEthernet1/0/3 VLANIF 6 100.3.1.2/24

Loopback1 - 3.3.3.9/32

P GigabitEthernet1/0/1 VLANIF 7 100.1.1.1/24

GigabitEthernet1/0/2 VLANIF 5 100.2.1.1/24

GigabitEthernet1/0/3 VLANIF 6 100.3.1.1/24

CE1 GigabitEthernet1/0/2 VLANIF 1 10.1.1.1/24

GigabitEthernet1/0/3 VLANIF 4 20.1.1.1/24

CE2 GigabitEthernet1/0/1 VLANIF 2 10.1.1.2/24

CE3 GigabitEthernet1/0/1 VLANIF 3 20.1.1.2/24

Configuration Roadmap

The configuration roadmap is as follows:

1. Configure a TE tunnel.

2. Configure a tunnel policy to bind the IP address of the remote end to the tunnel.

3. Apply the tunnel policy to the L2VC.

4. Connect the CEs to the backbone network.

Data Preparation

To complete the configuration, you need the following data:

l Tunnel policy

l VC ID

l Parameters for the MPLS TE tunnel

NOTE

For different L2VPN services from a PE to the same destination, different tunnel policies and TE tunnels

are required.

Procedure

Step 1 Enable PEs to communicate with each other.

# Configure an Interior Gateway Protocol (IGP) on the MPLS backbone network to implement

interworking between the PEs. IS-IS is used in this example, and the IS-IS process ID is 1.

# Configure PE1.

<Quidway> system-view

[Quidway] sysname PE1

[PE1] vlan 7

[PE1-vlan7] quit

[PE1] interface GigabitEthernet 1/0/1

1 VPN Tunnel Management

Quidway S9300 Terabit Routing Switch

Configuration Guide - VPN

1-40 Huawei Proprietary and Confidential

Issue 03 (2009-08-20)
