Keithley 4200-SCS User Manual

4200-900-01 Rev. K / February 2017 Return to Section Topics 2-49
Model 4200-SCS User’s Manual Section 2: Model 4200-SCS Software Environment
Figure 2-40
Device plan window containing an ITM to be submitted
3. If you want to submit the tests to a test library directory other than the default test library
directory,
*6
select the alternate test library directory in the Test Library box in the device plan
window.
NOTE Only the default test library directory is available in the Test Library box, unless other
test library directories were previously added through the directories tab of the KITE
Options window. The KITE Options window is accessed by selecting Options on the
Tools menu.
4. In the Test Library directory tree, select a destination folder that is appropriate for the tests.
5. In the Test Sequence Table of the device plan window, select the tests to be submitted.
NOTE You may select and submit multiple ITMs and UTMs at the same time. To select a
sequential group of ITMs and UTMs, hold down the Shift key while clicking the first
and last ITM / UTM in the sequence. To select a group of individual ITMs and UTMs,
hold down the Ctrl key while clicking the individual ITMs and UTMs.
Figure 2-41 shows the charg_char ITM selected in the Test Sequence Table, and the
Capacitor destination folder selected in the Test Library.
6. For example, the C:\S4200\kiuser\Tests factory-default directory or another directory that was specified as the
default using KCON, such as C:\S4200\YourName\Tests.
