4200-900-01 Rev. K / February 2017 Return to Section Topics 2-37
Model 4200-SCS User’s Manual Section 2: Model 4200-SCS Software Environment
NOTE You can specify the maximum number of Append executions and worksheets (the
maximum value of n). After the maximum number of Append worksheets have been
generated, the data from each Append execution replaces the data from the previous
Append execution. For example, if the maximum value of n is 4, the data from the
fifth Append execution replaces the data from the fourth Append execution. Refer
also to Reference Manual, Append execution of tests, test sequences, and Project
Plans, page 6-168.
• Each Append worksheet is labeled with a separate tab to distinguish it from the Data
worksheet for the test.
• Each Append worksheet contains the same columns and rows as the Data worksheet for
the test.
• Each Append worksheet may be manipulated in the same way as the Data worksheet for
the test.
See Figure 2-27.
Figure 2-27
Data and Append1 worksheets for a particular vcsat test
NOTE To display hidden Append worksheet tabs, use the scroll buttons located at the left
side of the tabs.
Figure 2-28
Append worksheet tabs
