Repair information 4-227
7462
4-bin mailbox assembly transport solenoid removal
1. Remove the 4-bin mailbox assembly left cover. See “4-bin mailbox assembly left cover removal” on
page 4-218.
2. Remove the left rear inner cover.
3. Disconnect the transport solenoid cable from the controller card.
4. Remove the screw (A) securing the transport solenoid to the 4-bin mailbox assembly.
5. Remove the transport solenoid and pull the cable through the left side frame.
