MacDon D1 Series - Page 113

215184 89 Revision A
1019682
A
Figure 3.173: Lower Brace Removal
4. Remove lower brace (A).
1015911
A
Figure 3.174: Stand Supports and Upper Brace
5. From the upper brace, remove two bolts (A). Repeat for the
opposite side.
ASSEMBLING THE HEADER AND FLOAT MODULE
