215184 164 Revision A
1015911
A
Figure 5.19: Stand Supports and Upper Brace
5. From the upper brace, remove two bolts (A). Repeat for the
opposite side.
1015917
A
B
Figure 5.20: Upper Brace and Stand Support Removal
6. Remove right and left fork channels (A).
7. Remove upper brace (B).
UNLOADING HEADER AT DEALER
