215184 298 Revision A
Figure 8.67: Rear Wheel Axle, Wheel Bearings, Frame/Wheel Pivot, and Front Wheel Pivot
1017324
A
B
C
A - Wheel Bearings (Four Places) B - Front Wheel Pivot (One Place) C - Frame/Wheel Pivot (One Place) Both Sides
