215184 437 Revision A
Figure 9.287: John Deere Combine Display
8. Select HEADER (A) from the list of calibration options.
Figure 9.288: John Deere Combine Display
9. With HEADER selected, press icon (A). The icon will
turn green.
Figure 9.289: John Deere Combine Display
10. Press icon (A) and instructions will appear on screen to
guide you through the remaining calibration steps.
NOTE:
If an error code appears during calibration, the sensor is out
of voltage range and will require adjustment. For
instructions, refer to Checking Voltage Range from the
Combine Cab – John Deere S and T Series, page 431.
NOTE:
If float was set heavier to complete the AHHC calibration
procedure, adjust to recommended operating float after
the calibration is complete.
SETTING UP AUTO HEADER HEIGHT CONTROL
