MacDon D1 Series - Page 484

215184 460 Revision A
1022797
A
B
Figure 9.347: John Deere S7 Display – Calibrations and
Procedures
6. Select HEADER tab (A).
7. Select HEADER CALIBRATION (B). The HEADER CALIBRATION
page displays.
1022799
A
Figure 9.348: John Deere S7 Display – Header
Calibration
8. Select CALIBRATE (A) at bottom of page. The calibration
overview window opens.
1022802
A
Figure 9.349: John Deere S7 Console
9. Press button (A) on console to set engine to high idle.
SETTING UP AUTO HEADER HEIGHT CONTROL
