MacDon D1 Series - Page 63

215184 39 Revision A
1031791
E
F
B
A
C
D
Figure 3.46: Cam Link to Tine Tube on Six-Bat Reel
A - Tine Bar Crank B - Link
C - Bolt D - Shim (not visible)
E - Cam Arm F - Preinstalled Stud
D
1031792
E
F
A
B
C
Figure 3.47: Cam Link to Tine Tube on Nine-Bat Reel
A - Tine Bar Crank B - Link
C - Bolt D - Shim (not visible)
E - Cam Arm F - Preinstalled Stud
NOTE:
Pictures to the right are provided for additional reference.
Proceed to 3.4 Attaching Reel Height Sensor, page 133.
ASSEMBLING THE HEADER AND FLOAT MODULE
