DMTA-10004-01EN, Rev. D, November 2016
Configuring the Instrument
133
and overwrite the old readings with the new inspection data.
When database tracking is selected, the following measurement related
parameters are automatically adjusted to match those stored at the current ID
number:
○ Alarm mode (on/off)
○ Alarm set points
○ Differential mode (on/off)
○ Differential reference value
○ Min/max mode (min/max/off)
○ Extended blank value
○ Resolution
○ Units
○ Gain
○ Velocity
○ Transducer type (user prompt only)
When database tracking is selected and a waveform is stored at the current ID
number, the following additional waveform related parameters are
automatically adjusted to match those stored with that waveform:
○ Range
○ Zoom (on/off)
○ Extended blank position
○ Rectification mode (full wave, half wave negative, half wave positive, RF)
If the database does not have any data stored at the current ID number, then
the setup remains unchanged.
Even if database tracking is activated, you can override the settings for the current ID
number by manually changing any setup parameter.
d) Set B‑SCAN OUTPUT to ON to output the B-scan data when communicating
with the GageView interface program. Set it to OFF when communicating
with other interface programs that do not support the B-scan data. This
parameter only applies to files that have stored B-scan images.
