Select a large-sized group of targets. The camera chooses the
target used for focus from within the selected group.
Lar
g
eLar
g
e
lLarge
pC1–pC4 Custom Target
You can change the size of the AF target and the step (the distance it moves at one time).
Custom target modes can be selected when there is a check (P) next to a custom target in
[KAF Target Mode Settings] (P.109).
Release the multi selector when the desired mode is displayed.
AF target mode options will no longer be displayed.
The number of AF targets available may be reduced depending on shooting settings.
The AF target display can be accessed by pressing the multi selector. The multi selector can be
configured using [UCenter Button] (P.351).
Separate AF target modes can be selected according to camera orientation. g“Matching AF
Target Selection to Camera Orientation (KOrientation Linked Y)” (P.136)
The following focus settings can be recalled simultaneously using the Fn lever. Separate settings can
be assigned to Positions 1 and 2 of the Fn lever. Use this option to quickly adjust settings according
to shooting conditions.
[AF Mode] (P.100), [AF Target Mode] (P.106), and [AF Target Point] (P.105)
The Fn lever can be configured using the [KFn Lever Function] (P.353) item or the [nFn Lever
Function] (P.354) item.
You can adjust AF target settings for [C‑AF]. g[KC-AF Center Priority] (P.126)
Separate options can be selected for still photography and movie mode.
108
Choosing an AF Target Mode (AF Target Mode)
