Page #338 background image
Role Function
Digital Tele-
converter (K:
82x / n: 81.4x)
Turn the digital teleconverter on or off (P.259). Press once to zoom in and
again to zoom out.
You can turn it on/off even when you are recording a movie. During movie
recording, a frame indicating the area that will be magnified by the digital
teleconverter is displayed.
Keystone Comp.
(P)
(K only)
Press the control to view keystone compensation settings (P.264). After
adjusting settings, press the control again to exit. To cancel keystone
compensation, press and hold the control.
Fisheye
Compensation (N)
(K only)
Enable fisheye correction (P.266). Press once to enable fisheye correction.
Press again to disable. Hold the button and rotate the front or rear dial to
choose from [Angle] options 1, 2, and 3.
Magnify (8)
Press the control once to display the zoom frame and again to zoom
in (P.111). Press the control a third time to exit zoom; to hide the zoom
frame, press and hold the control. Use the multi selector, touch controls,
or FGHI to position the zoom frame.
HDR
(K only)
Enable HDR (P.253). Press once to enable HDR. Press again to disable.
Hold the button and rotate the front or rear dial to adjust [HDR] settings,
including HDR bracketing.
ISO
Adjust [ISO] settings (P.166). Hold the control and rotate the front or rear
dial. Alternatively, you can press the button to activate settings and then
rotate the dials. Highlight settings using the front or rear dial or HI.
WB(WB)
(white balance)
Adjust [WB] settings (P.228). Hold the control and rotate the front or rear
dial. Alternatively, you can press the button to activate settings and then
rotate the dials. Highlight settings using the front or rear dial or HI.
Multi Function
(Multi Fn)
(Multi-Function)
Configure the control for use as a multi-function button (P.344). Hold the
control and rotate the front or rear dial to choose the function performed.
The selected function can be performed by pressing the control.
Peaking (Peak)
Toggle focus peaking on or off (P.146). Press the control once to turn
peaking on and again to turn it off. When peaking is on, peaking options
(color, amount) can be displayed by pressing the INFO button.
338
Changing the roles of buttons (Button Settings)
