4.12 Test Run Checklist
SIEPCYEUOQ2V01A Q2V Technical Manual 137
Checked No. Description
18
When you use terminal AI2 for the frequency reference:
• Voltage input
– Set DIP Switch S1 on the drive to “V”.
– Set H3-09 = 0, 1 [AI2 Signal Level Select = 0 to 10V (Lower Limit at 0), 0 to +10V (Without Lower Limit)].
– Set H3-10 = 4 [AI2 Function Selection = Freq Ref/BIAS].
• Current input
– Set DIP Switch S1 on the drive to “I”.
– Set H3-09 = 2, 3 [AI2 Signal Level Select = 4 to 20 mA, 0 to 20 mA].
– Set H3-10 = 4 [AI2 Function Selection = Freq Ref/BIAS].
19
Make sure that the frequency reference gets to the necessary minimum and maximum values.
If drive operation is incorrect, make these adjustments:
• Gain Adjustment
Set the maximum voltage and current values, then adjust the analog input gain until the frequency reference is at the necessary value.
– For terminal AI1 input: H3-03
– For terminal AI2 input: H3-11
• Bias adjustment
Set the maximum voltage and current values, then adjust the analog input gain until the frequency reference is at the necessary value.
– For terminal AI1 input: H3-04
– For terminal AI2 input: H3-12
