6.3 Modbus Communications
208 SIEPCYEUOQ2V01A Q2V Technical Manual
Register No. (Hex.) Description
00D8
oFA0x Description (CN5-A)
bit 0 oFA00 [Option Not Compatible with Port]
bit 1 oFA01 [Option Fault/Connection Error]
bit 2 -
4
Reserved
bit 5 oFA05 [Option A/D Error]
bit 6 oFA06 [Option Communication Error]
bit 7 -
F
Reserved
00D9
oFA1x Description (CN5-A)
bit 0 oFA10 [Option RAM Error]
bit 1 oFA11 [Option Ope Mode Error]
bit 2 oFA12 [Drive Receive CRC Error]
bit 3 oFA13 [Drive Receive Frame Error]
bit 4 oFA14 [Drive Receive Abort Error]
bit 5 oFA15 [Option Receive CRC Error]
bit 6 oFA16 [Option Receive Frame Error]
bit 7 oFA17 [Option Receive Abort Error]
bit 8 -
F
Reserved
00DA Reserved
00DB
oFA3x Description (CN5-A)
bit 0 oFA30 [COM ID Error]
bit 1 oFA31 [Type Code Error]
bit 2 oFA32 [SUM Check Error]
bit 3 oFA33 [Option Receive Time Over]
bit 4 oFA34 [Modbus Time Over]
bit 5 oFA35 [Drive Receive Time Over 1]
bit 6 oFA36 [CI Check Error]
bit 7 oFA37 [Drive Receive Time Over 2]
bit 8 oFA38 [Control Reference Error]
bit 9 oFA39 [Drive Receive Time Over 3]
bit A oFA40 [CtrlResSel 1Err]
bit B oFA41 [Drive Receive Time Over 4]
bit C oFA42 [CtrlResSel 2Err]
bit D oFA43 [Drive Receive Time Over 5]
bit E -
F
Reserved
Register No. (Hex.) Description
00DC - 00E4 Reserved
00E5
Minor Fault Description 9
bit 0 EP24v [External Power 24V Supply]
bit 1 -
3
Reserved
bit 4 bAT [Keypad Battery Low Voltage]
bit 5 Reserved
bit 6 CP1 [Comparator 1 Limit Fault]
bit 7 CP2 [Comparator 2 Limit Fault]
bit 8 TiM [Keypad Time Not Set]
bit 9 bCE [Bluetooth Communication Error]
bit A -
F
Reserved
00E6 - 00E9 Reserved
00EA
Fault Description 11
bit 0 TiM [Keypad Time Not Set]
bit 1 bAT [Keypad Battery Low Voltage]
bit 2-
D
Reserved
bit E SCF [Safety Circuit Fault]
bit F Reserved
00EB - 00ED Reserved
00EE
Fault Description 12
bit 0 -
2
Reserved
bit 3 CP1 [Comparator 1 Limit Fault]
bit 4 CP2 [Comparator 2 Limit Fault]
bit 5 bCE [Bluetooth Communication Fault]
bit 6 -
F
Reserved
00EF - 00FA Reserved
00FB
Output Current
Note:
The unit of display is different for different models.
2001 to 2042, B001 to B018, 4001 to 4023: 0.01 A
2056 to 2082, 4031 to 4060: 0.1 A
■ Broadcast Messages
Broadcast messages are available as read-only. The undefined bit signal in the broadcast operation signal uses the
local data signal.
