1.1 Model Number and Nameplate Check
22 SIEPCYEUOQ2V01A Q2V Technical Manual
Table 1.3 Single-Phase AC 200 V Class
Model
HD Rating
[C6-01 = 0]
(Default)
ND Rating
[C6-01 = 1]
Maximum Applicable Motor
Output
kW
Rated output current
A
Maximum Applicable Motor
Output
kW
Rated output current
A
B001 0.1 0.8 0.18 1.2
B002 0.25 1.6 0.37 1.9
B004 0.55 3.0 0.75 3.5
B006 1.1 5.0 1.1 6.0
B010 1.5 8.0 2.2 9.6
B012 2.2 11.0 3.0 12.2
B018 4.0 17.6 - -
Table 1.4 Three-Phase AC 400 V Class
Model
HD Rating
[C6-01 = 0]
(Default)
ND Rating
[C6-01 = 1]
Maximum Applicable Motor
Output
kW
Rated output current
A
Maximum Applicable Motor
Output
kW
Rated output current
A
4001 0.37 1.2 0.37 1.2
4002 0.55 1.8 0.75 2.1
4004 1.1 3.4 1.5 4.1
4005 1.5 4.8 2.2 5.4
4007 2.2 5.6 3.0 7.1
4009 3.0 7.3 4.0 8.9
4012 4.0 9.2 5.5 11.9
4018 5.5 14.8 7.5 17.5
4023 7.5 18.0 11.0 23.4
4031 11.0 24.0 15.0 31.0
4038 15.0 31.0 18.5 38.0
4044 18.5 39.0 22.0 44.0
4060 22.0 45.0 30.0 60.0
