Receiving
1
1.1 Model Number and Nameplate Check
SIEPCYEUOQ2V01A Q2V Technical Manual 21
No. Description
3 A: IP20 protection Class
4 Input power supply voltage
• B: Single-Phase AC 200 V Class
• 2: Three-Phase AC 200 V Class
• 4: Three-Phase AC 400 V Class
5 Rated output current
Note:
Refer to the rated output current list for more information.
6
EMC noise filter
• A: Built-in EMC filter
• B: Without built-in EMC filter
7 Coating Specification
• A: Standard
8 Version
■ Rated Output Current
These output current values are applicable for drives that operate at standard specifications.
• These output current values are applicable for drives that operate at standard specifications.
• Derate the current in applications that:
– Increase the carrier frequency
– Have high ambient temperature
– Install drives side-by-side.
• Use C6-01 [ND/HD Duty Selection] to select Normal Duty rating (ND) or Heavy Duty rating (HD).
Table 1.2 Three-Phase AC 200 V Class
Model
HD Rating
[C6-01 = 0]
(Default)
ND Rating
[C6-01 = 1]
Maximum Applicable Motor
Output
kW
Rated output current
A
Maximum Applicable Motor
Output
kW (HP)
Rated output current
A
2001 0.1 0.8 0.18 1.2
2002 0.25 1.6 0.37 1.9
2004 0.55 3.0 0.75 3.5
2006 1.1 5.0 1.1 6.0
2008 1.1 6.9 1.5 8.0
2010 1.5 8.0 2.2 9.6
2012 2.2 11.0 3.0 12.2
2018 3.0 17.6 3.7 17.5
2021 4.0 17.6 5.5 21.0
2030 5.5 25.0 7.5 30.0
2042 7.5 33.0 11.0 42.0
2056 11.0 47.0 15.0 56.0
2070 15.0 60.0 18.5 70.0
2082 18.5 75.0 22.0 82.0
