Troubleshooting
7
7.4 Faults
SIEPCYEUOQ2V01A Q2V Technical Manual 223
Code Name Causes Possible Solutions
Electrical interference caused a communication data
error.
• Examine the control circuit lines, main circuit lines, and
ground wiring, and decrease the effects of electrical
interference.
• Make sure that a magnetic contactor is not the source of the
electrical interference, then use a Surge Protective Device if
necessary.
• Use only the recommended cables or other shielded line.
Ground the shield on the controller side or the drive input
power side.
• Separate the communication wiring from drive power lines,
and install a noise filter to the input side of the power supply
for communication.
• Decrease the effects of electrical interference from the
controller.
Note:
• The drive detects this error if it does not correctly receive control data for the CE detection time set to H5-09 [Mbus CE Detect Time].
• Do a Fault Reset to clear the fault.
• If the drive detects this error, the drive will operate the motor as specified by the stopping method set in H5-04 [Mbus Error Stop].
Code Name Causes Possible Solutions
CF Control Fault
Motor parameters are set incorrectly Correctly set the motor parameters and do Auto-Tuning again.
The torque limit setting is too low. Adjust L7-01 to L7-04 [Torque Limit].
The load inertia is too large. • Adjust C1-02, C1-04, C1-06, and C1-08 [Deceleration Times].
• Set the frequency reference to the minimum output frequency,
and stop the Run command when the drive stops deceleration.
The drive is trying to ramp to stop a machine that
cannot do ramp to stop or on a machine for which
deceleration is not necessary.
Correctly set b1-03 [Stopping Method Selection].
The motor and drive are connected incorrectly. Correct wiring errors.
Line-to-line Resistance Tuning is not done. Do Stationary Auto-Tuning for Line-to-Line Resistance.
The drive received a Run command while the motor
was coasting.
• Examine the sequence and input the Run command after the
motor fully stops.
• Set b3-01 = 1 [SpSrch@Start Selection = Enabled].
Note:
• The drive detects this error if the torque reference is more than the torque limit for 3 seconds or longer while the drive ramps to stop.
• Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
CoF Current Offset Fault
The drive starts operation while the induced voltage
stays in the motor (during coasting to a stop or after
fast deceleration).
• Make a sequence that does not restart operation when induced
voltage stays in the motor.
• Set b3-01 = 1 [SpSrch@Start Selection = Enabled].
• Use Speed Search from Fmax or Fref [H1-xx = 67, 68] to do a
speed search through one of the external terminals.
Note:
When controlling the PM motor, External Speed Search
commands 1 and 2 operate the same.
A drive hardware problem occurred. Replace the drive.
Note:
• The drive detects this error if the current offset value is more than the permitted setting range while the drive automatically adjusts the current offset.
• Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
CP1 Comparator 1 Limit Error
The monitor value set in H2-20 [Compare1 Mon.
Selection] was in the range of H2-21 [Compare1
Low Limit] and H2-22 [Compare1 Up Limit].
Examine the monitor value and remove the cause of the fault.
Note:
• The drive detects this error when H2-01 to H2-03 = 3C [MFDO Function Select = Comparator 1].
• Do a Fault Reset to clear the fault.
• Set the stopping method for this fault in H2-33 [Compare1 Protection Selection].
Code Name Causes Possible Solutions
CP2 Comparator 2 Limit Error
The monitor value set in H2-26 [Compare2 Mon.
Selection] was outside the range of H2-27
[Compare2 Low Limit] and H2-28 [Compare2 Up
Limit].
Examine the monitor value and remove the cause of the fault.
Note:
• The drive detects this error when H2-01 to H2-03 = 3D [MFDO Function Select = Comparator 2].
• Do a Fault Reset to clear the fault.
• Set the stopping method for this fault in H2-35 [Compare2 Protection Selection].
