7.4 Faults
224 SIEPCYEUOQ2V01A Q2V Technical Manual
Code Name Causes Possible Solutions
CPF00, CPF01,
CPF02, CPF03,
CPF06, CPF08,
CPF11 to
CPF14, CPF16
to CPF24,
CPF38
Control Circuit Error
A drive hardware problem occurred. • Re-energize the drive.
• If the fault stays, replace the control board or the drive. For
information about replacing the control board, contact the
manufacturer or your nearest sales representative.
Note:
• Do a Fault Reset to clear the fault.
• Fault trace is not available for these faults.
Code Name Causes Possible Solutions
CPF06 EEPROM Memory Data Error
The drive power supply was de-energized while a
communication option card entered a parameter
Write command.
Set A1-03 = 2220, 3330 [Init Parameters = 2-Wire Initialization,
3-Wire Initialization] and initialize the drive.
An EEPROM peripheral circuit error occurred. • Re-energize the drive.
• If the fault stays, replace the control board or the drive. For
information about replacing the control board, contact the
manufacturer or your nearest sales representative.
Note:
• The drive detects this error if there is an error in the data written to the EEPROM of the drive.
• Do a Fault Reset to clear the fault.
• Fault trace is not available for this fault.
Code Name Causes Possible Solutions
CPF25 Terminal Board not Connected
The terminal board is not correctly connected to the
drive.
1. De-energize the drive.
2. Correctly connect the terminal board to the drive.
3. Re-energize the drive.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
dCE1 Communication Error1
A drive hardware problem occurred temporarily due
to noise.
• Remove the cause of the noise.
• If the fault stays, replace the control board or the drive.
Note:
• Do a Fault Reset to clear the fault.
• Fault trace is not available for these faults.
Code Name Causes Possible Solutions
dCE2 Communication Error2
A drive hardware problem occurred temporarily due
to noise.
• Remove the cause of the noise.
• If the fault stays, replace the control board or the drive.
Note:
• Do a Fault Reset to clear the fault.
• Fault trace is not available for these faults.
Code Name Causes Possible Solutions
dEv Speed Deviation
The load is too heavy. Decrease the load.
Acceleration and deceleration times are set too
short.
Increase the values set in C1-01 to C1-08 [Acceleration/
Deceleration Time].
The dEv detection level settings are incorrect. Adjust F1-10 [Speed Dev Level] and F1-11 [Speed Dev Delay
Time].
The load is locked up. Examine the machine.
The holding brake is stopping the motor. Release the holding brake.
Note:
• The drive detects this error if the difference between the detected speed and the speed reference is more than the setting of F1-10 for longer than F1-11.
• Do a Fault Reset to clear the fault.
• If the drive detects this error, the drive will operate the motor as specified by the stopping method set in F1-04 [Speed Dev Detection Select].
Code Name Causes Possible Solutions
dv7 Polarity Judge Timeout
There is a disconnection in the motor coil winding. Measure the motor line-to-line resistance and replace the motor if
a coil is disconnected.
The screws on the drive output terminals are loose. Tighten the terminal screws to the correct tightening torque.
Note:
• The drive detects this error if it cannot detect polarity in a pre-set length of time.
• Do a Fault Reset to clear the fault.
