7.6 Parameter Setting Errors
248 SIEPCYEUOQ2V01A Q2V Technical Manual
Code Name Causes Possible Solutions
Settings for N.C. and N.O. input [H1-xx] for these
functions were selected at the same time:
• Setting value 34 [Fast Stop NO]
• Setting value 35 [Fast Stop NC]
Remove one of the function settings.
These settings were entered while H1-xx = 9 [Ext
Ref 1/2]:
• b1-15 = 4 [Freq. Ref. Sel. 2 = Pulse Train Input]
• H6-01 ≠ 0 [PI Pulse Train Function ≠ Freq Ref]
Set H6-01 = 0.
These settings were entered while H1-xx = 9 [Ext
Ref 1/2]:
• b1-15 = 3 [Option PCB] or b1-16 = 3 [Run
Comm. Sel 2 = Option PCB]
• No option is connected to the drive.
Connect an input option to the drive.
These settings were entered while H1-xx = 9 [Ext
Ref 1/2]:
• b1-15 = 1 [Analog Input]
• H3-02 ≠ 4 [AI1 Function Selection ≠ Freq Ref/
BIAS] or H3-10 ≠ 0 [AI2 Function Selection ≠
Freq Ref/BIAS]
Set H3-02 = 0 or H3-10 = 0.
These parameters are set at the same time:
• H1-xx ≠ 1A [Drive Enable]
• H2-xx = 2 [Drive Enable]
Correct the parameter settings.
These parameters are set at the same time:
• H6-01 ≠ 3 [PG Feedback]
• H1-xx = 15 [FWD/REV Det]
Correct the parameter settings.
These parameters are set at the same time:
• H1-xx = 65/66 [Up2 Command / Dw2
Command]
• H3-01, H3-09 = 1 [AI1 Signal Level Select, AI2
Signal Level Select = 0 to +10 V (Without Lower
Limit)]
Remove one of the function settings.
Code Name Causes Possible Solutions
oPE05 Run Cmd/Freq Ref Source Sel Err
The setting to assign the Run command or
frequency reference to an option card or the pulse
train input is incorrect.
Correct the parameter settings.
b1-01 = 3 [Freq. Ref. Sel. 1 = Option PCB] is set,
but there is no option card connected to the drive.
b1-02 = 3 [Run Comm. Sel 1 = Option PCB] is set,
but there is no option card connected to the drive.
Connect an option card to the drive.
These parameters are set at the same time:
• b1-01 = 4 [Pulse Train Input]
• H6-01 ≠ 0 [PI Pulse Train Function ≠ Freq Ref]
Set H6-01 = 0.
Code Name Causes Possible Solutions
oPE07 Analog Input Selection Error
The settings for H3-02 and H3-10 [MFAI Function
Select] and H7-30 [Virtual AIn Select Function]
overlap.
Set H3-02, H3-10, and H7-30 correctly to prevent overlap.
Note:
It is possible to set these functions to multiple analog input
terminals at the same time:
• Setting value 4 [Freq Ref/BIAS]
• Setting values 0 [Through Mode]
These parameters are set at the same time:
• H3-02, H3-10, H7-30 = F [PID Fbk]
• H6-01 = 1 [PI Pulse Train Function = PIDFbk
Value]
These parameters are set at the same time:
• H3-02, H3-10, H7-30 = 10 [PID SetPoint]
• H6-01 = 2 [PID SP Value]
These parameters are set at the same time:
• H3-02, H3-10, H7-30 = 10
• b5-18 = 1 [b5-19 PID SP Selection = Enabled]
These parameters are set at the same time:
• H6-01 = 2
• b5-18 = 1
Remove the function settings that are not in use.
