10.7 Drive Derating
302 SIEPCYEUOQ2V01A Q2V Technical Manual
■ Single-Phase 200 V Class
Table 10.14 Carrier Frequency and Rated Current Derating (Single-Phase 200 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
[C6-01 = 0]
Normal Duty Rating (ND)
[C6-01 = 1]
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
B001 0.8 0.8 0.8 0.8 0.7 0.6 1.2 1.1 1.0 0.9 0.8 0.6
B002 1.6 1.6 1.6 1.6 1.4 1.3 1.9 1.9 1.7 1.6 1.4 1.3
B004 3.0 3.0 3.0 3.0 2.7 2.4 3.5 3.5 3.2 3.0 2.7 2.4
B006 5.0 5.0 5.0 5.0 4.5 4.0 6.0 6.0 5.4 5.0 4.5 4.0
B010 8.0 8.0 8.0 7.5 7.0 6.4 9.6 9.1 8.3 7.7 7.1 6.4
B012 11.0 11.0 11.0 10.4 9.6 8.8 12.2 11.9 11.0 10.4 9.6 8.8
B018 17.6 17.6 17.6 16.6 15.3 14.1 21.0 19.8 18.1 17.0 15.5 14.1
Table 10.15 AOLV/PM Carrier Frequency and Rated Current Derating (Single-Phase 200 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
[C6-01 = 0]
Normal Duty Rating (ND)
[C6-01 = 1]
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
B001 0.8 0.8 0.8 0.7 0.6 0.5 1.2 1.1 0.9 0.8 0.6 0.5
B002 1.6 1.6 1.6 1.5 1.3 1.1 1.9 1.9 1.7 1.5 1.3 1.1
B004 3.0 3.0 3.0 2.8 2.4 2.0 3.5 3.5 3.1 2.8 2.4 2.0
B006 5.0 5.0 5.0 4.6 4.0 3.4 6.0 5.8 5.2 4.6 4.0 3.4
B010 8.0 8.0 7.8 7.1 6.4 5.7 9.6 8.8 8.0 7.2 6.4 5.6
B012 11.0 11.0 10.7 9.7 8.8 7.9 12.2 11.6 10.7 9.7 8.8 7.9
B018 17.6 17.6 17.1 15.6 14.1 12.6 21.0 19.3 17.5 15.8 14.1 12.3
■ Three-Phase 400 V Class
Table 10.16 Carrier Frequency and Rated Current Derating (Three-Phase 400 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
[C6-01 = 0]
Normal Duty Rating (ND)
[C6-01 = 1]
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4001 1.2 1.2 1.2 1.1 0.9 0.7 1.2 1.2 1.2 1.1 0.9 0.7
4002 1.8 1.8 1.8 1.6 1.3 1.1 2.1 2.1 1.8 1.6 1.3 1.1
4004 3.4 3.4 3.4 3.0 2.5 2.0 4.1 4.0 3.4 3.0 2.5 2.0
4005 4.8 4.8 4.8 4.3 3.6 2.9 5.4 5.4 4.8 4.2 3.6 2.9
4007 5.5 5.5 5.5 4.9 4.1 3.3 7.1 6.5 5.5 4.9 4.1 3.3
4009 7.3 7.3 7.3 6.5 5.4 4.4 8.9 8.6 7.3 6.5 5.4 4.4
4012 9.2 9.2 9.2 8.1 6.8 5.5 11.9 10.8 9.2 8.2 6.8 5.5
4018 14.8 14.8 14.8 13.1 11.0 8.9 17.8 17.3 14.7 13.1 11.0 8.8
4023 18.0 18.0 18.0 13.1 11.0 11 23.4 21.3 18.2 16.1 13.4 11
4031 24.0 24.0 24.0 21.3 17.8 14 31.0 28.2 24.1 21.3 17.9 14
4038 31.0 31.0 31.0 27.5 23.0 19 38.0 36.3 31.0 27.5 23.0 19
4044 39.0 39.0 39.0 34.5 29.0 23 44.0 44.0 39.0 34.5 29.0 23
4060 45.0 45.0 45.0 39.9 33.4 27 60.0 54.5 46.3 40.8 33.9 27
