11.4 b: APPLICATION
326 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b8-05
(01D0)
Expert
Power Det.Filter Time
Sets the time constant to measure output power.
20 ms
(0 - 2000 ms)
484
b8-06
(01D1)
Expert
Srch Op.Volt Limit
Sets the voltage limit for Search Operation as a percentage of the motor rated voltage.
0%
(0 - 100%)
484
b8-16
(01F8)
Expert
PM eSave Coef.Ki
Sets torque linearity. This parameter uses the Ki value from the motor nameplate.
Usually it is not necessary to change this setting.
1.00
(0.00 - 3.00)
484
b8-17
(01F9)
Expert
PM eSave Coef.Kt
Sets torque linearity. This parameter uses the Kt value from the motor nameplate.
Usually it is not necessary to change this setting.
1.00
(0.00 - 3.00)
485
b8-18
(01FA)
Expert
eSave d-Axis Filter Time
Sets the d-axis current reference filter time constant.
0.100 s
(0.000 - 5.000 s)
485
b8-19
(0B40)
Expert
eSave Search Frequency
Sets the frequency of Energy-saving control search operations. Usually it is not
necessary to change this setting.
Determined by A1-02
(10 - 300 Hz)
485
b8-20
(0B41)
Expert
PM eSave Width for Test
Sets the amplitude of Energy-saving control search operations.
1.0 degrees
(0.1 - 5.0 degrees)
485
b8-21
(0B42)
Expert
PM eSave Gain for Test
Sets the gain of Energy-saving control search operations.
0.3Hz
(0.1 - 20.0 Hz)
485
b8-22
(0B43)
Expert
PM eSave LPF Cutoff
Frq
Sets the frequency of the filter used to extract the high-efficiency phase from search
operations. Usually it is not necessary to change this setting.
10.0 Hz
(1.0 - 30.0 Hz)
486
b8-23
(0B44)
Expert
PM eSave Srch Limit
Sets the search operations output limit. Usually it is not necessary to change this setting.
15.0 degrees
(0.0 - 30.0 degrees)
486
b8-24
(0B45)
Expert
PM eSave HiF Gain for
ACR
Sets the gain for high-frequency current control.
200.0 Hz
(100.0 - 1000.0 Hz)
486
b8-25
(0B46)
Expert
PM eSave Srch Start
Level
Sets the start level for search operations.
10.0%
(0.0 - 100.0%)
486
b8-26
(0B47)
Expert
PM eSave Pwr SP
Setpoint
Sets a value to increase torque accuracy.
0.0%
(-10.0 - +10.0%)
486
b8-28
(0B8B)
Expert
OverExc Action
Selection
Sets the function for excitation operation.
0 : Disabled
1 : Enabled
0
(0, 1)
486
b8-29
(0B8C)
eSave Priority Mode
Sets the priority of drive response between changes to the load or Energy-saving
control. Enable this to prioritize energy-saving control. Disable this to prioritize
tracking related to fast load changes, and prevent motor stall.
0 : Priority: Drive Response
1 : Priority: Energy Savings
0
(0, 1)
486
