Parameter Details
12
12.2 b: APPLICATION
SIEPCYEUOQ2V01A Q2V Technical Manual 481
■ b5-89: Sleep Method Selection
No.
(Hex.)
Name Description
Default
(Range)
b5-89
(0B89)
RUN
Sleep Method Selection
Sets sleep and wake up operation when using PID.
0
(0, 1)
0 : Standard
1 : EZ Sleep/Wake-up
■ b5-90: EZsleep Unit
No.
(Hex.)
Name Description
Default
(Range)
b5-90
(0B90)
EZsleep Unit
Sets the measurement units for b5-91 [EZsleep Min Spd] and b5-92 [EZsleep Level].
0
(0, 1)
0 : rpm
1 : 0.1Hz units
■ b5-91: EZsleep Min Spd
No.
(Hex.)
Name Description
Default
(Range)
b5-91
(0B91)
RUN
EZsleep Min Spd
Sets the minimum speed for the EZ Sleep/Wakeup function. This parameter uses the largest value
from b5-91, b5-34 [PID Out Low Limit Level], and d2-02 [FRef Lower Limit].
0.0 Hz or 0 min
-1
(r/min)
(0.0 to 590.0 Hz or 0 to
35400 min
-1
(r/min))
Note:
The value of b5-90 [b5-91: EZsleep Unit] sets the units. When b5-90 changes, this parameter does not automatically update. Set this
parameter again after you change b5-90 is changed.
■ b5-92: EZsleep Level
No.
(Hex.)
Name Description
Default
(Range)
b5-92
(0B92)
RUN
EZsleep Level
Sets the value that the output frequency or motor speed must be less than for longer than b5-93
[EZsleep Time] to enter Sleep Mode.
0.0 Hz or 0 min
-1
(r/min)
(0.0 to 590.0 Hz or 0 to
35400 min
-1
(r/min))
Note:
When b5-90 [EZsleep Unit] changes, this parameter does not automatically update. Set this parameter again after you change b5-90.
■ b5-93: EZsleep Time
No.
(Hex.)
Name Description
Default
(Range)
b5-93
(0B93)
RUN
EZsleep Time
Sets the length of time that the output frequency or motor speed must be less than b5-92 [EZsleep
Level] to enter Sleep Mode.
5.0 s
(0.0 - 1000.0 s)
■ b5-94: EZsleep Wake Level
No.
(Hex.)
Name Description
Default
(Range)
b5-94
(0B94)
RUN
EZsleep Wake Level
Sets the level at which the drive resumes operation when exiting Sleep Mode.
0.00%
(0.00 - 600.00%)
Note:
The values of b5-20 [PID Unit Selection], b5-38 [PID SP User Scale for Display], and b5-39 [PID SP User digits for Display] set the
units. When b5-20, b5-38, and b5-39 change, this parameter does not automatically update. Set this parameter again after you change
b5-20, b5-38, and b5-39 are changed.
• When b5-95 = 1 [EZsleep Wake Mode = Absolute]:
When b5-09 = 0 [PID Output Level Selection = Normal output], and the PID Feedback [H3-xx = F] is less than
the value of b5-94 for a time longer than the value of b5-96 [EZsleep Wake Time], the drive will exit sleep and
