12.2 b: APPLICATION
480 SIEPCYEUOQ2V01A Q2V Technical Manual
Note:
• Set b5-01 = 1 to enable this parameter.
• When b5-61 = 1, you can use this formula to adjust PID output proportional to the frequency reference:
U5-03 [PID Output], Fref [Frequency Reference], and Fmax [Maximum Output Frequency]
*1 Lower limit = b5-62, Upper limit = Maximum output frequency
■ b5-62: PID LoLim Value for Trim Mode
No.
(Hex.)
Name Description
Default
(Range)
b5-62
(119B)
PID LoLim Value for Trim
Mode
Sets the PID Trim Mode Lower Limit Value as a percentage of the maximum output frequency.
0.00%
(0.00 - 100.00%)
Note:
Set b5-01 = 1 to enable this parameter.
■ b5-63: PID DifFB Mon Selection
No.
(Hex.)
Name Description
Default
(Range)
b5-63
(119C)
PID DifFB Mon Selection
Selects the monitor (Ux-xx) used as the PID Differential Feedback. Set the x-xx part of the Ux-xx
[Monitor].
000
(000 - 999)
Note:
• You cannot select parameter U5-xx.
• This parameter is disabled when set to 000.
■ b5-64: PID DifFB Mon Gain
No.
(Hex.)
Name Description
Default
(Range)
b5-64
(119D)
PID DifFB Mon Gain
Sets the gain for the monitor specified in b5-63 [PID DifFB Mon Selection].
1.00
(0.00 - 10.00)
■ b5-65: PID DifFB Mon Bias
No.
(Hex.)
Name Description
Default
(Range)
b5-65
(119F)
PID DifFB Mon Bias
Sets the bias for the monitor specified in b5-63 [PID DifFB Mon Selection].
0.00
(-10.00 - +10.00)
■ b5-66: PID Fback Mon Level
No.
(Hex.)
Name Description
Default
(Range)
b5-66
(11DE)
PID Fback Mon Level
Sets the signal level for the monitor specified in b5-55 [PID Fback Mon Selection].
0
(0, 1)
0 : Absolute
1 : Bi-directional (+/-)
■ b5-67: PID DifFB Mon Level
No.
(Hex.)
Name Description
Default
(Range)
b5-67
(11DF)
PID DifFB Mon Level
Sets the signal level for the monitor specified in b5-63 [PID DifFB Mon Selection].
0
(0, 1)
0 : Absolute
1 : Bi-directional (+/-)
