12.8 L: PROTECTION
636 SIEPCYEUOQ2V01A Q2V Technical Manual
■ L1-08: oL1 Current Level
No.
(Hex.)
Name Description
Default
(Range)
L1-08
(1103)
oL1 Current Level
Sets the reference current for the motor 1 thermal overload detection. When the current level > 0.0
A, you cannot set this value < 10% of drive rated current.
0.0 A
(0.0 A or 10% to 150% of
the drive rated current)
When L1-08 = 0.0 A, the drive uses E2-01 [Mot Rated Current (FLA)] to detect the motor overload protection. In
PM control mode, the drive uses E5-03 [PM Mot Rated Current (FLA)] to detect the motor overload protection.
When L1-08 ≠ 0.0 A, the set value is the reference for motor overload protection.
Note:
• Display is in these units:
–0.01 A: 2001 to 2042, B001 to B018, 4001 to 4023
–0.1 A: 2056 to 2082, 4031 to 4060
• When the current level > 0.0 A, you cannot set this value < 10% of drive rated current.
■ L1-09: M2 oL1 Curr.Level
No.
(Hex.)
Name Description
Default
(Range)
L1-09
(1104)
M2 oL1 Curr.Level
Sets the reference current for the motor 2 thermal overload detection. When the current level > 0.0
A, you cannot set this value < 10% of drive rated current.
0.0 A
(0.0 A or 10 to150% of the
drive rated current)
When L1-09 = 0.0 A, the drive uses E4-01 [M2 Rated Current (FLA)] to detect the motor overload protection.
When L1-09 ≠ 0.0 A, the set value is the reference for motor overload protection.
Note:
• Display is in these units:
–0.01 A: 2001 to 2042, B001 to B018, 4001 to 4023
–0.1 A: 2056 to 2082, 4031 to 4060
• When the current level > 0.0 A, you cannot set this value < 10% of drive rated current.
■ L1-13: Motor oL1 Memory Selection
No.
(Hex.)
Name Description
Default
(Range)
L1-13
(046D)
Motor oL1 Memory
Selection
Sets the function that keeps the current electronic thermal protector value when the drive stops
receiving power.
1
(0, 1)
0 : Disabled
1 : Enabled
Sets if the drive will calculate the motor again when the drive is energized again.
■ L1-22: LeakCurrFil Tim1
No.
(Hex.)
Name Description
Default
(Range)
L1-22
(0768)
RUN
LeakCurrFil Tim1
Sets the leakage current detection reduction filter time constant during constant speed run.
Determined by C6-02
(0.0 - 60.0 s)
Note:
You can set this parameter when C6-02 = B [Carrier Frequency Selection = Leakage Current Rejection PWM].
If incorrect detection of alarms, for example oL1 [Motor Overload], occur or errors occur in the values on the
current monitor because of a leakage current, increase the setting value.
■ L1-23: LeakCurrFil Tim2
No.
(Hex.)
Name Description
Default
(Range)
L1-23
(0769)
RUN
LeakCurrFil Tim2
Sets the leakage current detection reduction filter time constant during acceleration/deceleration.
Determined by C6-02
(0.0 - 60.0 s)
